[Wiki] Model 3 / Model Y - Technische Veränderungen

Release Model 3 Highland Long Range!

  • Internal Naming → „Tesla Model 3H“

  • Variant / Version → H5LD#Qb1## → Highland - LG 5L NMC79 - Dual Motor

  • Maximum vehicle design speed → 201 km/h

  • Weights:

    • Mass of the vehicle in running order → 1899 kg
    • Reference mass → 1861 kg
    • Vehicle test mass → 1924 kg
    • Maximum mass → 2263 kg
    • Front axle → 958 kg
    • Rear axle → 941 kg
    • Load Capacity → 414kg - 477kg (~50kg more than M3 Refresh)
  • Motors:

    • DU CAT 2 → 3D3 / 3D7A
    • Maximum net power →
      Front: (3D3A (drive unit)): 158 kW @ 6625 min-1,
      Rear:(3D7A (drive unit)): 208 kW @ 6500 min-1
    • Maximum 30 minutes power →
      Front: (3D3A (drive unit)): 65 kW
      Rear:(3D7A (drive unit)): 88 kW
    • Maximum net torque →
      Front: (3D3A (drive unit)): 240 Nm @ 0 - 6200 min-1,
      Rear:(3D7A (drive unit)): 350 Nm @ 500 – 5500 min-1
    • Test DC voltage ->335 V
    • Maximum Current → Rear 655A / Front 630A
  • Battery:

    • Tesla E31 aka „5L“
    • Nominal voltage → 345 V
    • Number of cells → 4416
    • Battery Mass → 456 kg
    • Battery Capacity → 230 Ah
    • Battery Energy → 79 kWh
  • Gearbox:

    • Ratio → 9,04
  • Wheels:

  • Axles:

  • WLTP „Vehicle High“ = 19" Wheels
